IKI WALL 9 kW
IKI WALL 9 kW
for 282-565 FT³ saunas
THE IKI WALL 9 kW ELECTRIC SAUNA HEATER IS the PERFECT CHOICE FOR YOUR SAUNA IF YOU ARE LOOKING FOR POWER AND CONVENIENCE
IKI WALL 9 KW BRINGS THE HEAT FOR LARGER 282-565 FT³ SAUNAS
This electric sauna heater, with a built-in or Wi-Fi control unit, and 9 kw of power, ensures that you are able to enjoy a relaxing sauna experience with consistent heat and robust steam. The heater’s wall-mounted design saves floor space and allows for easy installation.
With the heater depth of just 10.6 inched this slim but powerful heater takes very little space in your sauna, leaving room for a more creative bench design.
The front of the Wall heater is made of IKI’s signature stylish and durable stainless-steel mesh. The back of the heater is made of solid stainless-steel plate and helps the huge 308 lb stone mass the heater is able heat up in about an hour stay hot for a long time.
The large amount of stones in the heater enables luxuriously humid and comfortable sauna experience even on the lower benches of your sauna. For those who like it super hot, pour water on the stones on top of the heater and you’ll get hotter heat, as much as you can handle.
All IKI’s timeless and durable electric sauna heaters are built in Finland, hand-made from stainless steel and other high-quality materials that meet even the most demanding standards of the American customers. All IKI electric heaters are also UL certified.
All IKI electric heaters include a square heath shield (13.8” X 13.8”) for the ceiling of the sauna.
CONTROL UNIT OPTIONS FOR IKI ELECTRIC HEATERS
Built-in Control Unit
The heater model with a built-in control unit has a control unit mounted to the frame at the bottom of the heater with 1-hour operating time and 8 hour delay start feature. The temperature is controlled by the thermostat knob located next to the timer knob. More information can be found here.
Wi-Fi Control Unit
The heater model with a Wi-Fi Control unit is equipped with UKU Wi-Fi Remote Control Unit . With UKU Wi-Fi control unit you can turn your sauna on from the control panel or do it remotely from your phone by using the IKI mobile app. To use the mobile application the UKU control unit needs to be connected to a Wi-Fi network. The stylish black glass control panel can be mounted to the wall outside of the sauna or it can be surface-mounted to the wall. For surface mounting, the control panel requires a separate surface mounting frame(not included in the UKU control unit delivery).
INSTRUCTIONS
IKI Corner and Wall installation instruction >
Physical wiring diagram for IKI 9 kW electric heaters with built-in control units >
Physical Wiring diagram for IKI 9 kW electric heaters with UKU Wi-Fi control unit >
Instructions for UKU Wi-Fi Control Unit >
SAUNA STONES
If you choose to include sauna stones in your order (select from variant options) it will include 7 boxes of high-quality Olivine Diabase sauna stones. Stone Weight: 308 lb / 140 kg
SAFETY RAILING
You can increase the safety of your sauna by installing a safety railing around your electric heater.
The safety railing is made from untreated birch and can be tinted with any color to compliment your sauna interior.
Width (9 kW)
|
27.5 inches
|
HEATER SPECIFICATIONS
Size of sauna
|
282-565 ft³ / 8-16 m³
|
Max. amount of stones
|
308 lb / 140 kg
|
Height
|
50.8 inches / 130 cm
|
Width / Depth
|
18.5 / 10.6 inches | 47 / 27 cm
|
Heating time
|
45-60 min
|
Model number
|
MW10090NA
|
